Reduce costs – Werner & Weber Waste Compactors allow your business to reduce the size and volume of waste material through compressing and crushing. This reduces the number of hauls which lowers collection costs. Werner & Weber compactors prevent unauthorized access or disposal of material by ensuring waste and recyclables are contained. This improves both safety and appearance.
The area of application of these compactors is the compaction of high-volume waste, such as packaging, cardboard, films/foils, wooden cradles etc., from Industry, Hotels, Wholesale and Retail markets etc.
The Werner & Weber range of Waste Compactors are designed for very low maintenance and are simple to use. Waste can be fed continuously while the unit is cycling. All systems conform to the latest Health & Safety and CE requirements.
The compactors are available in various different forms, with a number of loading options, including front mounted Wheelie Bin Tippers with automatic lid opener, Front or side hinged loading doors and double end pick up.
From the small MPC-A.AT to the MPC-L.AT model, you can be certain that the portable waste compactors from Werner & Weber will give you efficient and trouble-free operation for years to come. No matter how big or small your business, we have a model that will work for you.
- For skip vehicle systems or roll-off tippers
- Extremely large filling opening (2370×1720 mm on MPC-L.AT)
- Enormous processing capacity (e.g. MPC-L.AT = 2.22m³/stroke)
- Extremely high compacting force, 370 KN on the cylinder of the MPCK-K/N/L.AT
- High fill weights, e.g. up to 4 tonnes and more of cardboard
- Low feed opening 1320/1410mm for comfortable loading
- Three-sided conical container for problem-free emptying
- Container sandblasted to ensure optimum corrosion protection
- Compactor designed in accordance with the EC Machinery Directive 2006/42/EC and German accident prevention regulations
- Machine TÜV certified (TÜV-MHF/MG03-04 753)
- Container 75% full light
- Pendulous steel scraper in front of the ram
- Ram with plastic fine scraper at the bottom (ideal for scraps of paper)
- Rubber seal on cylinder chamber maintenance hatch with safety limit switch
- Pendulous retaining claws prevent the waste from springing back
- Front hook can be folded down for easy filling
- Discharge door with ratchet closure, hinges on the side.
- Cylinder mounted in rotatable eyelets
- Innovative aluminium valve control block is practically maintenance-free.
- Maintenance friendly electrical switch cabinet and hydraulic unit are easily accessible from the side and from above.
- Electronic safety controller is easily expandable for many additional functions
- Container 100% full light
- End position of the ram “open” or “closed”
- Cable remote control
- Cover over filling opening on some variants
- Compactor pick up from both sides
- Discharge door with seal
- Additional integrated or portable container tipping mechanisms
- Fill level notification via GSM
MPC/K/N/L.AT – for hooklift
| Volume | Cylinder thrust | Loading height | Charge box dimensions | Swept volume | Cycle time | Volume per hour | Overall Dimensions* L x W x H | Weight* | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hopper | Clear aperture | Volume | |||||||||
| Model | [m3] | [kN] | [mm] | l/w [mm] | l/w [mm] | [m3] | [m3] | [sec.] | [m3/h] | [mm] | [kg] |
| MPC16-K.AT | 16 | 369 | 1410 | 1720 x 1710 | 950 x 1820 | 3,3 | 1,4 | 34 | 155 | 5660 x 2460 x 2660 | 4090 |
| MPC18-K.AT | 18 | 6060 x 2460 x 2660 | 4240 | ||||||||
| MPC20-K.AT | 20 | 6410 x 2460 x 2660 | 4650 | ||||||||
| MPC25-K.AT | 25 | 7250 x 2460 x 2660 | 5110 | ||||||||
| MPC18-N.AT | 18 | 369 | 1410 | 1720 x 2230 | 1450 x 1820 | 4,6 | 2,05 | 52 | 148 | 6580 x 2460 x 2660 | 4470 |
| MPC20-N.AT | 20 | 6930 x 2460 x 2660 | 4880 | ||||||||
| MPC23-N.AT | 23 | 7430 x 2460 x 2660 | 5210 | ||||||||
| MPC18-L.AT | 18 | 369 | 1410 | 1720 x 2370 | 1605 x 1820 | 4,99 | 2,22 | 56 | 153 | 6715 x 2460 x 2660 | 4980 |
| MPC20-L.AT | 20 | 7070 x 2460 x 2660 | 5110 | ||||||||
| MPC23-L.AT | 23 | 7570 x 2460 x 2660 | 5360 | ||||||||
| Motor 5.5kW / 400V, 50Hz || Standard CEE-5 pin socket, 16A Subject to technical modifications | * without additional equipment | ||||||||||
MPC-A.AT – for skiploader
| Volume | Cylinder thrust | Loading height | Charge box dimensions | Swept volume | Cycle time | Volume per hour | Overall Dimensions* L x W x H | Weight* | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hopper | Clear aperture | Volume | |||||||||
| Model | [m3] | [kN] | [mm] | l/w [mm] | l/w [mm] | [m3] | [m3] | [sec.] | [m3/h] | [mm] | [kg] |
| MPC8-A.AT | 8 | 230 | 1400 | 1410 x 1640 | 890 x 1500 | 2,1 | 1,0 | 22 | 176 | 4000 x 2020 x 2500 | 3210 |
| MPC10-A.AT | 10 | 4450 x 2020 x 2500 | 3360 | ||||||||
| MPC12-A.AT | 12 | 5200 x 2020 x 2500 | 3510 | ||||||||
| Motor 5.5kW / 400V, 50Hz || Standard CEE-5 pin socket, 16A Subject to technical modifications | * without additional equipment | ||||||||||
MPC-A.UR – for skiploader and hooklift
| Volume | Cylinder thrust | Loading height | Charge box dimensions | Swept volume | Cycle time | Volume per hour | Overall Dimensions* L x W x H | Weight* | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hopper | Clear aperture | Volume | |||||||||
| Model | [m3] | [kN] | [mm] | l/w [mm] | l/w [mm] | [m3] | [m3] | [sec.] | [m3/h] | [mm] | [kg] |
| MPC8-A.UR | 8 | 230 | 1450 | 1410 x 1640 | 890 x 1500 | 2,1 | 1,0 | 22 | 176 | 4320 x 2020 x 2640 | 3830 |
| MPC10-A.UR | 10 | 4770 x 2020 x 2640 | 3980 | ||||||||
| MPC12-A.UR | 12 | 5520 x 2020 x 2640 | 4130 | ||||||||
| Motor 5.5kW / 400V, 50Hz || Standard CEE-5 pin socket, 16A Subject to technical modifications | * without additional equipment | ||||||||||
